ABB AL9-30-10 Line Contactor

AL9-30-10 24V DC

General Information

  • Extended Product Type:
    AL9-30-10 24V DC
  • Product ID:
    1SBL143001R8110
  • EAN:
    3471522268815
  • Catalog Description:
    AL9-30-10 24V DC Contactor
Products Categories
Product Description
    • Long Description:
      AL 9 contactors are mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC or 220 V DC. The contactors can also be used for many other applications such as isolation, capacitor switching, lighting. The AL… series 1-stack 3-pole contactors are of the block type design. – Main poles and auxiliary contact blocks: 3 main poles, 1 built-in auxiliary contact, front and side-mounted add-on auxiliary contact blocks – Control circuit: DC operated with solid core magnet circuit. The polarity on the coil terminals (A1+ and A2-) must be respected – Accessories: a wide range of accessories is available. AL… contactors are fitted with low consumption DC coils and are suitable for a direct control by PLC outputs.

Ordering

  • Minimum Order Quantity:
    1 piece
  • Customs Tariff Number:
    85364900

Popular Downloads

Dimensions

  • Product Net Width:
    44 mm
  • Product Net Depth / Length:
    97 mm
  • Product Net Height:
    78 mm
  • Product Net Weight:
    0.52 kg

Technical

  • Number of Main Contacts NO:
    3
  • Number of Main Contacts NC:
    0
  • Number of Auxiliary Contacts NO:
    1
  • Number of Auxiliary Contacts NC:
    0
  • Rated Operational Voltage:
    Auxiliary Circuit 690 V
    Main Circuit 690 V
  • Rated Frequency (f):
    Auxiliary Circuit 50 / 60 Hz
    Main Circuit 50 / 60 Hz
  • Conventional Free-air Thermal Current (Ith):
    acc. to IEC 60947-4-1, Open Contactors Θ = 40 °C 26 A
    acc. to IEC 60947-5-1, Θ = 40 °C 16 A
  • Rated Operational Current AC-1 (Ie):
    (690 V) 40 °C 25 A
    (690 V) 55 °C 22 A
    (690 V) 70 °C 18 A
  • Rated Operational Current AC-3 (Ie):
    (415 V) 55 °C 9 A
    (440 V) 55 °C 9 A
    (500 V) 55 °C 9 A
    (690 V) 55 °C 7 A
    (380 / 400 V) 55 °C 9 A
    (220 / 230 / 240 V) 55 °C 9
  • Rated Operational Power AC-3 (Pe):
    (415 V) 4 kW
    (440 V) 4 kW
    (500 V) 5.5 kW
    (690 V) 5.5 kW
    (380 / 400 V) 4 kW
    (220 / 230 / 240 V) 2.2 kW
  • Rated Breaking Capacity AC-3:
    8 x Ie AC-3
  • Rated Making Capacity AC-3:
    10 x Ie AC-3
  • Rated Operational Current AC-15 (Ie):
    (500 V) 2 A
    (690 V) 2 A
    (24 / 127 V) 6 A
    (220 / 240 V) 4 A
    (380 / 400 V) 3 A
  • Short-Circuit Protective Devices:
    Auxiliary Circuit – gG Type Fuses 10 A
    gG Type Fuses 25 A
  • Rated Short-time Withstand Current Low Voltage (Icw):
    at 40 °C Ambient Temp, in Free Air, from a Cold State 10 s 100 A
    at 40 °C Ambient Temp, in Free Air, from a Cold State 15 min 26 A
    at 40 °C Ambient Temp, in Free Air, from a Cold State 1 min 50 A
    at 40 °C Ambient Temp, in Free Air, from a Cold State 1 s 250 A
    at 40 °C Ambient Temp, in Free Air, from a Cold State 30 s 60 A
    for 0.1 s 140 A
    for 1 s 100 A
  • Maximum Breaking Capacity:
    cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 440 V 250 A
    cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 690 V 100 A
  • Maximum Electrical Switching Frequency:
    (AC-1) 600 cycles per hour
    (AC-2 / AC-4) 300 cycles per hour
    (AC-3) 1200 cycles per hour
  • Rated Operational Current DC-13 (Ie):
    (24 V) 6 / 144 A
    (48 V) 2.8 / 134 A
    (72 V) 2 / 144 W
    (125 V) 1.1 / 138 W
    (250 V) 0.55 / 138 W
  • Rated Insulation Voltage (Ui):
    acc. to IEC 60947-4-1 1000 V
    acc. to IEC 60947-5-1 690 V
    acc. to UL/CSA 600 V
  • Rated Impulse Withstand Voltage (Uimp):
    8 kV
  • Mechanical Durability:
    10 million
  • Maximum Mechanical Switching Frequency:
    3600 cycles per hour
  • Rated Control Circuit Voltage (Uc):
    DC Operation 24 V
  • Coil Consumption:
    Average Holding Value, from Warm State 3 W
    Average Pull-in Value, from Cold State 3 W
  • Operate Time:
    Between Coil De-energization and NC Contact Closing 16 … 27 ms
    Between Coil De-energization and NO Contact Opening 10 … 17 ms
    Between Coil Energization and NO Contact Closing 50 … 100 ms
  • Mounting on DIN Rail:
    TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
    TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
  • Mounting by Screws (not supplied):
    2 x M4 screws placed diagonally
  • Connecting Capacity Main Circuit:
    Flexible with Cable End 0.75 … 2.5 mm²
    Rigid Cable 1 … 4 mm²
  • Connecting Capacity Auxiliary Circuit:
    Flexible with Cable End 0.75 … 2.5 mm²
    Rigid Cable 1 … 4 mm²
  • Degree of Protection:
    acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP20
    acc. to IEC 60529, IEC 60947-1, EN 60529 Coil Terminals IP20
    acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP20
  • Connecting Terminals (delivered in open position) Main Poles:
    M 3.5 (+,-) pozidriv 2 screw with cable clamp
  • Terminal Type:
    Screw Terminals

Technical UL/CSA

  • General Use Rating UL/CSA:
    (600 V AC) 21 A
  • Horsepower Rating UL/CSA:
    (200 … 208 V AC) Three Phase 2 hp
    (220 … 240 V AC) Three Phase 2 hp
    (440 … 480 V AC) Three Phase 5 hp
    (550 … 600 V AC) Three Phase 7-1/2 hp

Environmental

  • Ambient Air Temperature:
    Close to Contactor Fitted with Thermal O/L Relay -25 … 55 °C
    Close to Contactor without Thermal O/L Relay (0.85 … 1.1 Uc) -40 … 55 °C
    Close to Contactor without Thermal O/L Relay (Uc) -40 … 70 °C
    Close to Contactor for Storage -60 … +80 °C
  • Climatic Withstand:
    acc. to IEC 60068-2-30 and 60068-2-11 – UTE C 63-100 specification II
  • Maximum Operating Altitude Permissible:
    Without Derating 3000 m
  • Resistance to Shock acc. to IEC 60068-2-27:
    Closed, Shock Direction: A 20 g
    Closed, Shock Direction: B1 15 g
    Closed, Shock Direction: C1 20 g
    Closed, Shock Direction: C2 14 g
    Open, Shock Direction: A 10 g
    Open, Shock Direction: B1 5 g
    Open, Shock Direction: C1 8 g
    Open, Shock Direction: C2 8 g
    Shock Direction: B2 10 g

Material Compliance

  • REACH Declaration:
    2CMT2021-006202
  • RoHS Information:
    2CMT2021-006277
  • RoHS Status:
    Following EU Directive 2011/65/EU
  • WEEE B2C / B2B:
    Business To Business
  • WEEE Category:
    5. Small Equipment (No External Dimension More Than 50 cm)

Certificates and Declarations

Container Information

  • Package Level 1 Units:
    1 piece
  • Package Level 1 Width:
    86 mm
  • Package Level 1 Depth / Length:
    141 mm
  • Package Level 1 Height:
    51 mm
  • Package Level 1 Gross Weight:
    0.52 kg
  • Package Level 1 EAN:
    3471522268815
  • Package Level 2 Units:
    box 28 piece
  • Package Level 2 Gross Weight:
    14.56 kg
  • Package Level 3 Units:
    336 piece

Classifications

  • Object Classification Code:
    Q
  • ETIM 4:
    EC000066 – Magnet contactor, AC-switching
  • ETIM 5:
    EC000066 – Magnet contactor, AC-switching
  • ETIM 6:
    EC000066 – Power contactor, AC switching
  • ETIM 7:
    EC000066 – Power contactor, AC switching
  • ETIM 8:
    EC000066 – Power contactor, AC switching
  • eClass:
    V11.0 : 27371003
  • UNSPSC:
    39121529
  • IDEA Granular Category Code (IGCC):
    4756 >> Capacitor magnet contactor
  • E-Number (Finland):
    3709177
Product Catalogue

ABB AL9-30-10 Line Contactor
