| Module No. | MPL-B320P-HJ74AA |
| Product name | SERVO MOTOR; MP SERIES; KINETIX; PERMANENT MAGNET ROTARY MOTOR; LOW INERTIA; 240 VAC; 130 MM FRAME; 3 INCH STACK |
| Product description | MPL-B320P-HJ74AA Servo Motor, KINETIX; PERMANENT MAGNET ROTARY MOTOR | Allen Bradley |
| Part number | MPLB320PHJ74AA |
| Allen Bradley recommendation product | MPL-B320P-RK72AA SERVO MOTOR, MP SERIES, KINETIX, PERMANENT MAGNET ROTARY MOTOR | Allen Bradley |
| Voltage | 230 VAC, 240 VAC, 480 VAC |
| Manufacturer | Allen Bradley |
| Country of origin | United States |
| Warranty | 1-2 year |
| Shipping Method | 1.Ship worldwide, usually 5-7 days. 2. We use DHL, FedEx, UPS,TNT |
| Remark | If you need a specific firmware or series relating to MPL-B320P-HJ74AA, please call or email us, we probably have it in our large inventory. |
