MPL-B860D-MJ72AA Servo Motor, Rotary | Allen Bradley
Type number: MPL-B860D-MJ72AA, Part No.: MPLB860DMJ72AA, from manufacturer: Allen Bradley, Catagory: MPL Low Inertia Drives & Motors, Servo Motor, Rotary, Low Inertia
della101@163.com
Products Categories
Product Description
| Module No. | MPL-B860D-MJ72AA |
| Product name | Low Inertia, IEC, 480V AC, 1024 Sin/Cos, 2000 rpm Maximum, 83 N-M, 1/4 Turn Right Angle Rotatable DIN … |
| Product description | MPL-B860D-MJ72AA Servo Motor, Rotary | Allen Bradley |
| Part number | MPLB860DMJ72AA |
| Allen Bradley recommendation product | MPL-B860D-MJ74AA MP SERIES; KINETIX; PERMANENT MAGNET ROTARY MOTOR, Servo Motor | Allen Bradley |
| Voltage | 230 VAC, 240 VAC, 480 VAC |
| Manufacturer | Allen Bradley |
| Country of origin | United States |
| Warranty | 1-2 year |
| Shipping Method | 1.Ship worldwide, usually 5-7 days. 2. We use DHL, FedEx, UPS,TNT |
| Remark | If you need a specific firmware or series relating to MPL-B860D-MJ72AA, please call or email us, we probably have it in our large inventory. |
Product Catalogue
MPL-B860D-MJ72AA Servo Motor, Rotary | Allen Bradley
| Motor Cat. No. | Rated Speed
rpm |
Maximum
Speed rpm |
System Continuous Stall Current
A 0-pk |
System Continuous
Stall Torque N•m (lb•in) |
System Peak
Stall Current A 0-pk |
System Peak
Stall Torque N•m (lb•in) |
Motor Rated Output
kW |
Kinetix 5700 Drives (480VAC input) |
| MPL-B860D | 2000 | 2000 | 47.5 | 83.0 (735) | 95.5 | 152.5 (1350) | 12.5 | 2198-S086-ERSx |
| MPL-B880C | 1500 | 1500 | 47.5 | 110 (973) | 97.5 | 203 (1797) | 12.6 | 2198-S086-ERSx |
| MPL-B880D | 2000 | 2000 | 67.0 | 110 (973) | 96.0 | 147 (1301) | 12.6 | 2198-S130-ERSx |
| MPL-B960B | 1200 | 1200 | 42.5 | 130 (1150) | 94.0 | 231 (2044) | 12.7 | 2198-S086-ERSx |
| MPL-B960C | 1500 | 1500 | 55.0 | 124.3 (1100) | 121.6 | 219.8 (1945) | 14.8 | 2198-S086-ERSx |
| 125 | 226 (2000) | 2198-S130-ERSx | ||||||
| MPL-B960D | 2000 | 2000 | 70.0 | 124.3 (1100) | 125 | 226 (2000) | 15.0 | 2198-S130-ERSx |
| MPL-B980B | 1000 | 1000 | 40.0 | 162.7 (1444) | 94.0 | 278 (2460) | 15.2 | 2198-S086-ERSx |
| MPL-B980C | 1500 | 1500 | 68.2 | 158.2 (1400) | 140 | 271.2 (2400) | 16.8 | 2198-S130-ERSx |
| MPL-B980D | 2000 | 2000 | 79.0 | 158.2 (1400) | 140 | 260 (2300) | 18.6 | 2198-S130-ERSx |
| MPL-B980E | 1500 | 2750 | 105 | 141 (1250) | 226.2 | 233 (2062) | 13.0 | 2198-S160-ERSx |
| 230 | 237 (2100) | 2198-S263-ERSx |
