VPL-A1002C-CJ12AA VPL Low Inertia Motors | Allen Bradley
Type number: VPL-A1002C-CJ12AA, Part No.: VPLA1002CCJ12AA, from manufacturer: Allen Bradley, Catagory: Kinetix VP Servo Motors Drives & Motors, VPL Low Inertia Motors
della101@163.com
| Module No. | VPL-A1002C-CJ12AA |
| Product name | 240V AC, 100mm Bolt Circle Frame Size, 2 (Two) Magnet Stacks, C Winding, 2500 RPM Rated Speed, … |
| Product description | VPL-A1002C-CJ12AA VPL Low Inertia Motors | Allen Bradley |
| Part number | VPLA1002CCJ12AA |
| Allen Bradley recommendation product | VPL-A1002C-CJ12AS Servo Motor, Low Inertia | Allen Bradley |
| Voltage | 230 VAC, 240 VAC, 480 VAC |
| Manufacturer | Allen Bradley |
| Country of origin | United States |
| Warranty | 1-2 year |
| Shipping Method | 1.Ship worldwide, usually 5-7 days. 2. We use DHL, FedEx, UPS,TNT |
| Remark | If you need a specific firmware or series relating to VPL-A1002C-CJ12AA, please call or email us, we probably have it in our large inventory. |
VPL-A1002C-CJ12AA VPL Low Inertia Motors | Allen Bradley
Motor Dimensions (063 mm and 075 mm frame sizes)
Dimensions are in mm(in.)
Pilot Diameter Tolerance!
VPL-A/B063xx Motors:
039.995…40.011(1.5746…1.5752)
VPL-A/B075xx Motors: 059.993…60.012(2.3619…2.3627)
Shaft Diameter Tolerances
VPL-A/B063ax Motors:
08.998…9.007(0.3543.…0.3546)
VPL-A/B075xx Motors:
010,997…11.008(0.4330.…0.4334)
Detail A
| Shaft,Pilot,and
Keyway Tolerances |
VPL-A/B063xx | VPL-A/B075xx |
| Shaft Runout (IL.R.) | 0.030(0.0012) | 0.035(0.0014) |
| Pilot Eccentiaity (Il.R. | 0.08(0.0031) | 0.08(0.0031) |
| Max Face Runout (II.R) | 0.08(0.0031) | 0.08(0.0031) |
| Keyway Depth (GE) | 1.80.…1.90
(0.071…0.075) |
2.50…2.60
(0.098..0.102) |
| Keyway Width (F) | 2.971…2.996
(0.117…0.118) |
3.970…4.000
(0.156…0.158) |
| Shaft-end
Threaded Hole |
Thread-M3x0.5-6H
Thread Depth-9.0 (0.354) |
Thread-M4x0.7-6H
Thread Depth-10.0(0.393) |
Motor Dimensions (063 and 075 mm frame sizes)
| Motor
Cat.No. |
AD
MM in.) |
HD
mm in.) |
LA
mm (in.) |
LD(1) mm(in | LE(1) mm(in. | L)
mm(in.) |
LB(1) mm(in.) | L-LR(2
mm(in |
D(4) mm
(in.) |
M
mm(in.) |
s(3)
MM in.) |
N(4) mm
(in.) |
P
MM in.) |
GE(4)
MM (in.) |
F(4) mm(in.) |
| VPL-A/B0631 |
69.5 (2.74) |
97.0 (3.82) |
9.0 (0.35) |
100.2
(3.94) |
60.3
(2.37) |
143.1
(5.63) |
123.1
(4.85) |
20.0 (0.787) |
9.0 (0.354) |
63.0 (2.480) |
5.80 (0.234) |
40.0 (1.575) |
55.0 (2.17) |
1.90 (0.075) |
3.0 (0.118 |
| VPL-A/B0632 | 125.2
(4.93) |
85.3
(3.36) |
168.1
(6.61) |
148.1
(5.83) |
|||||||||||
| VPL-A/B0633 | 150.2
(5.91) |
110.3
(4.34) |
193.1
(7.59) |
173.1
(6.81) |
|||||||||||
| VPL-A/B0751 |
77.0 (3.03) |
112.0 (4.41) |
9.0 (0.35) |
102.0
(4.02) |
62.1
(2.44) |
147.9
(5.82) |
124.9
(4.92) |
23.0 (0.906) |
11.0 (0.433) |
75.0 (2.953) |
5.80 (0.234) |
60.0 (2.362) |
70.0 (2.76) |
2.60 (0.102) |
4.0 (0.157) |
| VPL-A/B0752 | 127.0
(5.00) |
87.1
(3.43) |
172.9
(6.80) |
149.9
(5.90) |
|||||||||||
| VPI-A/B0753 | 152.0
(5.98) |
112.1
(4.41) |
197.9
(7.79) |
174.9
(6.89 |
(1)If ordering an VPL-A/B063xr or VPL-A/B07Sax motor with brake,add 30.6mm(1.20 in.)to dimension L,LB,LE,and LD.
(2)Tolerance for this dimension is±0.7mm(±0.028in.).
(3) Tolerance for this dimension is+0.3,-0.0mm(±0.006in.).
(4)For keyway,shaft diameter,and pilot diameter tolerances,see the diagram or Shaft Pilot .and Keyway Iolerances table above.
Motors are designed to metric dimensions.Inch dimensions are approximate conversions from millimeters.Dimensions without tolerances are for reference.
