VPL-B0631U-PJ14AS Low Inertia AC Servo Motor | Allen Bradley
Type number: VPL-B0631U-PJ14AS, Part No.: VPLB0631UPJ14AS, from manufacturer: Allen Bradley, Catagory: Kinetix VP Servo Motors Drives & Motors, VPL Low Inertia Motors
della101@163.com
| Module No. | VPL-B0631U-PJ14AS |
| Product name | SERVO MOTOR; MP SERIES; KINETIX; PERMANENT MAGNET ROTARY MOTOR; LOW INERTIA; 240 VAC; 130 MM FRAME; 3 INCH STACK |
| Product description | VPL-B0631U-PJ14AS Low Inertia AC Servo Motor | Allen Bradley |
| Part number | VPLB0631UPJ14AS |
| Allen Bradley recommendation product | VPL-B0631U-PK14AS VPL series Low-Inertia motor from the VPL Series servo motors | Allen Bradley |
| Voltage | 230 VAC, 240 VAC, 480 VAC |
| Manufacturer | Allen Bradley |
| Country of origin | United States |
| Warranty | 1-2 year |
| Shipping Method | 1.Ship worldwide, usually 5-7 days. 2. We use DHL, FedEx, UPS,TNT |
| Remark | If you need a specific firmware or series relating to VPL-B0631U-PJ14AS, please call or email us, we probably have it in our large inventory. |
VPL-B0631U-PJ14AS Low Inertia AC Servo Motor | Allen Bradley
MMA-B180xxx Motor Dimensions(1)
| Motor Series | A mm (in.) | B mm (in.) | BA mm (in.) | BC mm (in.) | C mm (in.) | C1 mm (in.) | L(2) mm (in.) | LR mm (in.) | LA mm (in.) | LB (2) | LBR mm (in.) | W mm (in.) | H mm (in.) | HC mm (in.) | HD mm (in.) | HDR mm (in.) | K mm (in.) |
| MMA-B180Axx MMA-B180Bxx MMA-B180Cxx MMA-B180Dxx |
279 (10.98) | 400 (15.75) |
60 (2.36) |
65 (2.56) |
121 (4.76) |
91 (3.58) | 1100 (43.31) | 1075 (42.32) |
18 (0.71) | 960 (37.80) | 935 (36.81) | 174 (6.85) |
180 (7.09) |
360 (14.17) |
527 (20.75) |
833 (32.80) |
Ø 16 (0.63) |
| 520 (20.47) | 1220 (48.03) | 1195 (47.04) | 1080 (42.52) | 1055 (41.53) | 294 (11.57) | ||||||||||||
| 590 (23.23) | 1290 (50.79) | 1265 (49.80) | 1150 (45.27) | 1125 (44.29) | 364 (14.33) | ||||||||||||
| 640 (25.20) | 1340 (52.75) | 1315 (51.77) | 1200 (47.24) | 1175 (46.26) | 414 (16.30) |
(1) LR, LBR, and HDR are specific to radial motors. L, LB, and HD are specific to axial motors.
(2) For all motors except those with no holding brake, catalog option (MMA-B180xxx–xxxx22xxxxxxx), add 140 mm (5.51 in.) to dimension Land LB.
MMA-B180xxx Shaft Dimensions
| Motor Cat. No. | Shaft Options | Key Width F mm (in.) | Shaft Width Over Key GA mm (in.) | Depth of Keyway GE mm (in.) | Key Length | Diameter D mm (in.) | Shaft Length | Thread Size TS mm (in.) |
| MMA-B180Axx | A, B, C, D | 18 (0.71) | 64 (2.52) | 7 (0.28) | 130 (5.12) | 60 (2.36) | 140 (5.51) | M20 |
| E, F | NA | |||||||
| MMA-B180Bxx, MMA-B180Cxx, MMA-B180Dxx | A, B, C, D | 18 (0.71) | 69 (2.72) | 7 (0.28) | 130 (5.12) | 65 (2.56) | 140 (5.51) | M20 |
| E, F | NA | |||||||
IMPORTANT There are no flange options for MMA-B180xxx motors. The HDR dimension is the overall height of the radial blower.
